SPECS

FRAME:

• SIZES one size
• COLORS Black, Mushroom
• FRAME ALUXX-grade aluminum
• FORK high-tensile steel, rigid
• SHOCK N/A

COMPONENTS:

• HANDLEBAR Giant Kids, alloy, 31.8mm, 10-degree rise, 60mm, custom taper design
• GRIPS Giant Junior, custom taper design
• STEM forged alloy Ahead, 10-degree
• SEATPOST alloy, single-bolt, 27.2x250mm
• SADDLE Explora Jr.
• PEDALS platform

DRIVETRAIN:

• SHIFTERS Shimano REVOSHIFT, 1x7
• FRONT DERAILLEUR N/A
• REAR DERAILLEUR Shimano Tourney
• BRAKES alloy, linear pull
• BRAKE LEVERS alloy, junior MTB
• CASSETTE 14x34
• CHAIN KMC HV500
• CRANKSET steel, 32t, 140mm
• BOTTOM BRACKET semi-cartridge

WHEELS:

• RIMS Giant Kids 24", alloy
• HUBS nutted, 28h
• SPOKES stainless, 14g
• TIRES Giant Junior Sport, 24x1.95", 22 tpi
• EXTRAS bell, kickstand, fender, rear derailleur protector
• Recommended Retail Price: $550.00

GEOMETRY

FRAME: One Size

• Seat Tube Angle 72.0°
• Top Tube Length (inch) 20.5
• Head Tube Length (inch) 5.5
• Head Tube Angle 70.0°
• Wheelbase (inch) 38.4
• Chain Stay Length (inch) 16.1
• Stack (inch) 20.3
• Reach (inch) 13.9
• Stand Over Height (inch) 20.7
• Crank Length (inch) 5.5

*All specifications and prices listed are subject to change without notice.
